Mecer 2KVA Rackmount UPS, ME-2000-WPRU

Mecer 2000VA / 1600W 2U ON-LINE SINE WAVE Rackmountable UPS (with Monitoring Software) -Black. 2000 VA / 1600 W, Pure Sine Wave, 12 V / 9 Ah batteries x4, Voltronic Power Winner Pro Online pure sine wave UPS.

Mecer 2KVA Winner Pro Rackmount UPS, ME-2000-WPRU specifications

• Model: ME-2000-WPRU
• Capacity: 2000VA / 1600W
• Topology: True On-Line, Double Conversion
• Form Factor: Rackmount (1U or 2U, depending on model)
• Input Voltage: 220/230/240 VAC
• Input Voltage Range: 176 ~ 276 VAC at 100% load; 110 ~ 176 VAC at 50% load
• Input Frequency: 50 Hz / 60 Hz (Auto Sensing)
• Input Power Factor: ≥ 0.99 at full load
• Output Voltage: 220/230/240 VAC
• Output Frequency: 50 Hz / 60 Hz ± 1 Hz
• Waveform Type: Pure Sine Wave
• Output Power Factor: 0.8
• Transfer Time: Zero (On-Line Mode)
• Battery Type: Sealed Lead Acid (Maintenance-Free)
• Battery Capacity: 12V / 9Ah x 2
• Backup Time: 5-15 minutes (depending on load)
• Recharge Time: 4-6 hours to 90% capacity
• Battery Protection: Discharge protection, Overcharge protection
• Display: LCD Panel for status monitoring (Input/Output Voltage, Frequency, Battery Level, Load Level, etc.)
• Communication Interface: RS-232, USB, Smart Slot for optional SNMP card
• Software: Monitoring and shutdown software (Compatible with Windows, Linux, Unix, Mac)
• Audible Alarm: Battery Mode, Low Battery, Overload, Fault
• Protection: Short Circuit, Overload, Surge, and Spike Protection
• Efficiency: Up to 94% in online mode
• ECO Mode Efficiency: Up to 98%
• Operating Temperature: 0°C – 40°C
• Operating Humidity: 0% – 95% Non-Condensing
• Noise Level: < 50 dB at 1 meter
• Dimensions: Approx. 440 x 500 x 88 mm (W x D x H)
• Weight: Approx. 15 kg
• Cooling: Forced air cooling with temperature-controlled fans
• Certifications: CE, ISO 9001
• Additional Features:
  • Cold start capability
  • ECO mode for energy saving
  • Intelligent fan control for noise reduction
  • Hot-swappable battery design for continuous operation during battery replacement
  • Advanced battery management for extended battery life
  • Rackmount design suitable for data centers and server rooms
  • LCD display with multi-functional indicators for real-time monitoring
  • External battery pack connection for extended runtime

Specifications and features
Product Code	ME-2000-WPRU
CAPACITY	2000 VA / 1600 W
PHASE	Single phase with ground
INPUT
Input Voltage Range	55-150 VAC or 110-300 VAC (Based on load at 50%); 85-140VAC or 160-280VAC (Based on load at 100%)
Nominal Voltage	100/110/115/120/127VAC or 200/208/220/230/240VAC
Frequency Range	40Hz ~70 Hz
Power Factor	>= 0.99 @ Nominal Voltage (100% load)
OUTPUT
Voltage Regulation	± 1%
Output Voltage	100/110/115/120/127VAC or 200/208/220/230/240VAC
Frequency Range (Batt. Mode)	50 Hz ± 0.25 Hz or 60 Hz ± 0.3 Hz
Transfer Time : AC Mode to Battery Mode	Zero
Transfer Time : Inverter to Bypass	4 ms (Typical)
Transfer Time : Waveform (Batt. Mode)	Pure Sine Wave
Current Crest Ratio	3::1
Harmonic Distortion	— 3% THD (Linear Load); — 6% THD (Non-linear Load)
Frequency Range (Synchronized Range)	47~53 Hz or 57~63 Hz
EFFICIENCY
Battery Mode	0.87
AC Mode	0.89
BATTERY
Long-run Model : Battery Type	Depending on the capacity of external batteries
Long-run Model : Charging Current (max.)	1A/2A/4A/6A (Adjustable)
Long-run Model : Charging Voltage	54.7 VDC ± 1%, 82.1 VDC ± 1%, 109.4VDC ±1%
Long-run Model : Numbers	4, 6, 8
Standard Model : Battery Type	12 V / 9 AH
Standard Model : Charging Current (max.)	1A
Standard Model : Charging Voltage	54.7 VDC ± 1%
Standard Model : Numbers	4
Standard Model : Typical Recharge Time	4 hours recover to 90% capacity
INDICATORS
LCD	Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators
ALARM
Battery Mode	Sounding every 4 seconds
Low Battery	Sounding every second
Overload	Sounding twice every second
Fault	Continuously sounding
ENVIRONMENT
Operating Humidity	20~90% RH @ 0- 40°C (non-condensing)
Noise Level	Less than 50dB @ 1 Meter
PHYSICAL
Standard Model : Dimension, D x W x H (mm)	410 x 438 x 88 [2U]
Standard Model : Net Weight (kgs)	19
Long-run Model : Dimension, D x W x H (mm)	410 x 438 x 88 [2U]
Long-run Model : Net Weight (kgs)	12
