APC 950VA Backup UPS, 230V AVR IEC Sockets, BX950UI
APC Back-UPS 950VA USB connections your PC to access additional power protection and management feature for your UPS via a USB Port. Telephone data line surge protection provides protection of connected equipment from power surges traveling on telephone lines.
APC Back-UPS 950VA Automatic Voltage Regulation (AVR)Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
950VA APC UPS Back-UPS Features & Benefits: ProtectionBattery and surge protected outlets Back up and protect your hardware and data during power outages, surges and spikes.
Surge-only outlets Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.
950VA APC UPS Specification
- Model: APC BX950UI
- Type: Line-Interactive UPS
- Power Capacity: 950 VA / 480 Watts
- Input Voltage: 230V (nominal)
- Input Voltage Range: 140V – 300V (without battery usage)
- Input Frequency: 50/60 Hz ± 5 Hz (auto-sensing)
- Output Voltage: 230V (nominal)
- Output Frequency: 50/60 Hz ± 1 Hz (auto-sensing)
- Waveform Type: Stepped Approximation to Sine Wave
Battery Specifications
- Battery Type: Sealed Lead Acid (SLA), maintenance-free
- Battery Voltage: 12V DC
- Typical Runtime:
- At Full Load (480W): Approximately 2-4 minutes
- At Half Load (240W): Approximately 10-15 minutes
- Recharge Time: 6-8 hours to 90% capacity
- Hot-Swappable Batteries: No
Physical Specifications
- Form Factor: Tower
- Dimensions:
- Height: 215 mm (8.5 inches)
- Width: 130 mm (5.1 inches)
- Depth: 336 mm (13.2 inches)
- Weight: Approximately 6.0 kg (13.23 lbs)
Output Connections
- Output Connections:
- 4 x IEC 320 C13 outlets (2 battery backup + surge protection, 2 surge protection only)
Management & Communications
- Status Indicators: LED status indicators for power and battery status
- Communication Ports:
- USB port (for monitoring via APC PowerChute software)
- Software Compatibility: APC PowerChute for monitoring, graceful shutdown, and power management
Protection Features
- Surge Protection: Yes, provides protection from surges and spikes (156 Joules)
- Overload Protection: Yes, with automatic bypass in case of overload
- Short Circuit Protection: Yes
- Automatic Voltage Regulation (AVR): Boost and Trim AVR corrects high and low voltage conditions without using the battery
- Cold Start Capability: Yes, provides temporary battery power when utility power is unavailable
Environmental Specifications
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Storage Temperature: -15°C to 45°C (5°F to 113°F)
- Operating Humidity: 0% to 95% non-condensing
- Operating Elevation: 0 to 3000 meters (0 to 10,000 feet)
Certifications and Compliance
- Safety Approvals: IEC/EN 62040-1
- EMC Compliance: IEC/EN 62040-2
- Environmental Compliance: RoHS
Model Name |
APC Back-UPS 950VA, 230V, AVR, IEC Sockets
|
|
---|---|---|
Includes |
User Manual
|
|
Standard Lead Time |
Usually in Stock
|
|
Product Distribution |
Afghanistan
|
Output Power Capacity |
480 Watts / 950 VA
|
|
---|---|---|
Max Configurable Power (Watts) |
480 Watts / 950 VA
|
|
Nominal Output Voltage |
230V
|
|
Output Frequency (sync to mains) |
50/60 Hz +/-1 Hz
|
|
Line Interactive
|
||
Waveform Type |
Stepped approximation to a sinewave
|
|
Output Connections |
(1) IEC Jumpers (Battery Backup)
|
Nominal Input Voltage |
230V
|
|
---|---|---|
Input Frequency |
50/60 Hz +/- 3 Hz (auto sensing)
|
|
Input Connections |
IEC-320 C14
|
|
Cord Length |
1.22 meters
|
|
Input voltage range for main operations |
150 – 280 V
|
|
Maximum Input Current |
4 A
|
|
Input Breaker Capacity |
7 A
|
Battery Type |
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
|
|
---|---|---|
Included Battery Modules |
1
|
|
Typical recharge time |
8 hour(s)
|
Interface Port(s) |
USB
|
|
---|---|---|
Control panel |
LED status display with On Line : On Battery : Replace Battery and Overload indicators
|
|
Audible Alarm |
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
|
Surge energy rating |
273 Joules
|
|
---|---|---|
Data Line Protection |
RJ-11 Modem/Fax protection
|
Maximum Height |
215.0 mm
|
|
---|---|---|
Maximum Width |
130.0 mm
|
|
Maximum Depth |
336.0 mm
|
|
Net Weight |
8.0 kg
|
|
Shipping Weight |
8.99 kg
|
|
Shipping Height |
295.0 mm
|
|
Shipping Width |
245.0 mm
|
|
Shipping Depth |
440.0 mm
|
|
Color |
Black
|
Operating Environment |
0 – 40 °C
|
|
---|---|---|
Operating Relative Humidity |
0 – 95 (non-condensing) %
|
|
Operating Elevation |
0-3000 meters
|
|
Storage Temperature |
-15 – 45 °C
|
|
Storage Relative Humidity |
0 – 95 (non-condensing) %
|
|
Storage Elevation |
0-9000 meters
|
|
Audible noise at 1 meter from surface of unit |
45.000 dB
|
Approvals |
A-tick
|
|
---|---|---|
Standard warranty |
2 years repair or replace
|
