Suprema OM-120 Multiple Output Extension Module Mall+254
Suprema OM-120 Multiple Output Extension Module is a multiple output extension module which controls up to 12 output relays. It can be used as elevator controller with BioStar 2 system. Max. 31 units can be connected to a master device via RS485 daisy chain. OM-120 can also support anti-pass back zone and fire alarm zone features.
Specification
| General | CPU | Cortex M3 72MHz |
| Memory | Flash 128KB, SRAM 20KB | |
| LED | Multi-color- Power 1 ea– Relays 12 ea
– RS-485 2 ea – AUX IN 1 ea – Status 1 ea |
|
| Operating temperature | -20°C ~ 60°C | |
| Storage temperature | -40°C ~ 70°C | |
| Operating humidity | 0% ~ 95%, non-condensing | |
| Storage humidity | 0% ~ 95%, non-condensing | |
| Dimension (W x H x D) | 90 mm x 190 mm x 21 mm | |
| Weight | 300 g | |
| Certificates | CE, FCC, KC, RoHS, REACH, WEEE | |
| Output | TTL Output x 6 | |
| Interface | RS-485 | 1ch |
| AUX input | 2ch Dry Contact Input | |
| Relay | 12 Relays | |
| Electrical | Power | Voltage: 12 VDCCurrent: Max. 1 A |
| Switch input VIH | Max. 5 V (Dry Contact) | |
| Relay | Voltage: Max. 30 VDCCurrent: 5 A |
