Inverter 300 VA Mall+254

Sollatek Inverter 300 VA deliver fully isolated ″clean″ sinusoidal output voltage of 115VAC at 400Hz/60Hz or 230VAC at 50Hz. They typically operate from 24V, 48V, 110V or 125Vdc sources. Efficiency is a minimum of 80% at full load, depending on input/output configuration. The input and output are filtered for low noise. The input meets EN55022 Class A conducted and radiated requirements. An output-fail alarm (Form C) and remote shutdown or enable are available as options.

Inverter 300 VA comply with C22.2 No. 107.1 – 01, UL 458 and EN/UL60950-1 and equivalent industrial safety standards. Protection features include inrush current limiting, input to output isolation, output current limiting with short-circuit protection and thermal shutdown with self-resetting.

All models in the Sollatek Inverter 300 VA series operate at full specification (no de-rating) over a 0°C to +50°C temperature range. Extended temperature ranges are available on request. Cooling is by conduction to customer heat-sink or chassis and by natural convection.

Sollatek Inverter 300 VA designs and manufactures a wide range of industrial and railway quality sine wave power conversion products. All designs can be customized. We also design and manufacture fully custom units.

Sollatek Inverter 300 VA specifications
