Hikvision DS-2TD2617B-6/PA Temperature Screening Camera Mall+254

Hikvision DS-2TD2617B-6/PA Temperature Screening Terminal from the leading Hikvision dealer, buy online Hikvision DS-2TD2617B-6/PA Temperature Screening Terminal and have it delivered.

DS-2TD2617B-6/PA Outdoor Thermal & Optical Network Bullet Camera from Hikvision uses a vanadium oxide uncooled focal plane array to capture 160 x 120 resolution video that can be upscaled to 320 x 240 resolution. The camera’s 6.2mm fixed thermal lens delivers a 25 x 18.7° field of view.

• VOx Uncooled Focal Plane Arrays
• Resolution160×120
• Pixel Interval17μm
• Response Waveband8μm to 14μm
• NETDLess than 40 mK (@25°C,F#=1.1)
• Focal Length6.2mm
• IFOV2.74 mrad
• ApertureF1.1
• Field Of View25° × 18.7° (H × V)
• Min. Focusing Distance0.6 m

• Optical
• Image Sensor1/2.7″ Progressive Scan CMOS
• Resolution2688×1520, 4MP
• Min. IlluminationColor: 0.0089 Lux @ (F1.6, AGC ON), B/W: 0.0018 Lux @ (F1.6, AGC ON)
• Field Of View39.42° × 22.14° (H × V)
• Focal Length8mm
• Shutter Speed1s to 1/100,000s
• White BalanceAuto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Daylight Lamp/Sodium Lamp
• Day & Night ModeIR cut filter with auto switch
• WDR120 dB

• Illuminator
• IR DistanceUp to 40 m
• IR Intensity And AngleAutomatically adjusted

• Feature
• Bi-Spectrum Image FusionDisplay the details of optical channel on thermal channel
• Picture In PictureDisplay partial image of thermal channel on the full screen of optical channel

• Smart Function
• Temperature RangeFrom 30°C to 45°C (86°F ~ 113°F)
• Temperature Accuracy± 0.5 °C

• Network
• Main StreamThermal: 25fps(1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240);Optical: 50Hz: 25fps (2688 × 1520), 25fps (1920 × 1080), 25fps (1280 × 720);Optical: 60Hz: 30fps (2688 × 1520), 30fps (1920 × 1080), 30fps (1280 × 720)
• Sub StreamThermal: 25fps(704 × 576, 352 × 288, 320 × 240);Optical: 50Hz: 25fps (704 × 576), 25fps (352 × 288), 25fps (176 × 144);Optical: 60Hz: 30fps (704 × 480), 30fps (352 × 240), 30fps (176 × 120)
• Video CompressionH.264 (Baseline/Main/High Profile) /MJPEG/H.265
• Audio CompressionG .711u/G.711a/G.722.1/MP2L2/G.726/PCM
• ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
• APIONVIF (Profile S, Profile G, Profile T), ISAPI, SDK
• SecurityPassword protection, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP over HTTPS
• Simultaneous Live ViewUp to 20

• Interface
• ClientiVMS-4200, Hik-Connect
• Web BrowserPlug-in required: IE8-IE11, Chrome 41-44, Firefox 30.0-51
• Alarm Input2-ch inputs (0-5 VDC)
• Alarm Output2-ch relay outputs, alarm response actions configurable
• Alarm ActionSD recording/Relay output/Smart capture/FTP upload/Email linkage
• Audio Input1, 3.5 mm Mic in/Line in interface. Line input: 2 – 2.4 V [p-p], output impedance: 1 KΩ ± 10%
• Audio OutputLinear Level; Impedance: 600Ω
• Communication Interface1, RJ45 10M/100M Self-adaptive Ethernet interface. 1, RS-485 interface
• On-Board StorageBuilt-in MicroSD card slot, supporting MicroSD/SDHC/SDXC card (up to 256 G), supports manual/alarm recording
