| Camera |
| Image Sensor |
1/3″ progressive scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON) |
| Shutter Speed |
1/3 s to 1/100, 000 s |
| Slow Shutter |
Yes |
| Auto-Iris |
No |
| Day &Night |
IR cut filter |
| DNR (Digital Noise Reduction) |
3D DNR |
| WDR (Wide Dynamic Range) |
Digital WDR |
| Angle Adjustment (Bracket) |
Pan: 0° to 360°, tilt: 0°to 180°, rotation: 0° to 360° |
| Lens |
| Focal length |
2.8 mm, 4 mm, 6 mm |
| Aperture |
F2.0 |
| Focus |
No |
| FOV |
2.8 mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117°, 6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 58° |
| Lens Mount |
M12 |
| IR |
| IR Range |
Up to 30 m |
| Wavelength |
850 nm |
| Compression Standard |
| Video Compression |
Main stream: H.265/H.264, Sub stream: H.265/H.264/MJPEG |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.264+ |
Main stream supports |
| H.265 Type |
Main Profile |
| H.265+ |
Main stream supports |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Smart Feature-set |
| Region of Interest |
1 fixed region for main stream and sub-stream |
| Image |
| Max. Resolution |
2560 × 1440 |
| Main Stream |
50Hz: 20fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Max. Frame Rate |
60Hz: 20fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub-stream |
50Hz: 20fps (704 × 576, 352 × 288, 640 × 480, 320 × 240) |
| Max. Frame Rate |
60Hz: 20fps (704 × 480, 352 × 240, 640 × 480, 320 × 240) |
| Image Enhancement |
BLC, 3D DNR |
| Image Setting |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or |
| web browser |
| Day/Night Switch |
Auto, scheduled |
| Network |
| Network Storage |
NAS (NFS, SMB/CIFS) |
| Alarm Trigger |
Motion detection, video tampering alarm, illegal login |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, |
| SNMP, IGMP, 802.1X, QoS, IPv6 UDP, Bonjour |
| General Function |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
